Electromagnetic Brain Animation - Patent 7771341

Abstract

This invention pertains to apparatus methodology formulated to perform electromagnetic brain animation (EBA) for the purpose of partial or complete alleviation of specific mental impairments relating categorically to infant, early childhood, and adolescent target populations. EBA expressly refers to an original system and mechanized manner for determining and redirecting particular areas of the brain found to suffer from endemic and/or environmental injury. Electromagnetic brain animation is an enhanced initiative for positive influence on brain region neuron activity with the impetus to habilitate, rehabilitate and/or redirect dysfunctional cellular structure in direct correlation with greater pliability of evolving nervous systems in conjunction with superior biological plasticity due to specified group cluster. The EBA technical inclination, evolution and fruition of "animation" are specifically related to safety and success with early developing brains. Special areas targeted, but not limited to, include depression, dysthymia, attention deficit disorder, learning disability, memory loss, overanxious disorder, mild retardation, and autism.

1. A method for non-invasive excitation of specific brain neurons, comprising: projecting a combination of electromagnetic radiation and ultrasound pulses on to
a specific area of a brain that is known to impact or result in precise emotional and/or mental difficulties; wherein the ultrasound pulses are initiated from a cap configured to conform to a human head; wherein the electromagnetic radiation is
initiated from a plurality of coils connected to the cap; and wherein the combination of electromagnetic radiation and ultrasound induce cell or neuron depolarization for the purpose of enhancement, habilitation, rehabilitation, and/or redirection of
said abnormal mental difficulties.

2. A cap instrument configured to be placed in physical proximity to a human head, for causing neuron depolarization for ameliorating the effects of a mental disorder, the apparatus comprising: the cap instrument comprising: a plurality of
coils arranged in rows on the cap configured to emit a rate of pulses of a electromagnetic radiation when energized with electric current, wherein the pulses have a pulse frequency; and an adjustment mechanism connected to the cap for adjusting the
distance of the coils from the head for focusing the electromagnetic radiation into the head when the cap is worn by the head; an ultrasound attachment for generating ultrasonically induced electric fields within a brain; and wherein instrument is
configured to emit pulses with a pulse frequency above 50 Hz.

3. A method for stimulating a specific area of a brain using an induction device, comprising: recording the spatial structure of the brain; generating a live (present time) model of the brain and specific regions via schematic screen
combinations of topography; projecting a combination of electromagnetic radiation and ultrasound pulses on to a specific area of the brain that is known to impact or result in emotional or mental disorders; wherein the ultrasound pulses are initiated
from a cap configured to conform to a human head; wherein the electromagnetic radiation is initiated from a plurality of coils connected to the cap; and wherein the combination of electromagnetic radiation and ultrasound induce cell or neuron
depolarization for ameliorating mental disorders.

4. The method of claim 1, further comprising configuring the shapes of the coils to target a region of the brain.

5. A method for non-invasive excitation of specific brain neurons, comprising: preconditioning an area of the brain by targeting an ultrasound beam on to the area; projecting electromagnetic radiation pulses onto the area of the brain that is
known to impact or result in emotional or mental disorders, wherein the radiation is emitted in a sequence of pulses, wherein the duration of each pulse in the sequence is less than 10 milliseconds and wherein the pulses in the sequence alternate in
polarity; and post treating the area of the brain with an ultrasound beam; wherein the combination of electromagnetic radiation and ultrasound induce cell or neuron depolarization for ameliorating mental disorders.

6. An apparatus for causing neuron depolarization for ameliorating the effects of a mental disorder, the apparatus comprising: a cap instrument configured to be placed in physical proximity to a human head, for comprising: a plurality of coils
arranged in rows on the cap configured to emit a sequence of pulses of a electromagnetic radiation when energized with electric current, wherein the pulses have a pulse frequency; and an adjustment mechanism connected to the cap for adjusting the
distance of the coils from the head for focusing the electromagnetic radiation into the head when the cap is worn by the head; an ultrasound attachment for generating ultrasonically induced electric fields within a brain; and wherein the pulse
sequences comprise of a series of waves greater than 1000 amps in electrical current and less than 10,000 amps and the pulse sequences are in the range of 5-50 seconds in duration, wherein the combination results in having each wave between less than 1
millisecond in duration to 1 tenth of 1 millisecond in duration and the magnetic field produced thereby is at least 1 to 3 Tesla.

7. An apparatus for causing neuron depolarization for ameliorating the effects of a mental disorder, the apparatus comprising: a cap instrument configured to be placed in physical proximity to a human head, for comprising: a plurality of coils
arranged in rows on the cap configured to emit a sequence of pulses of a electromagnetic radiation when energized with electric current, wherein the pulses have a pulse frequency; and an adjustment mechanism connected to the cap for adjusting the
distance of the coils from the head for focusing the electromagnetic radiation into the head when the cap is worn by the head; an ultrasound attachment for generating ultrasonically induced electric fields within a brain; and wherein the pulses range
from 5 seconds to 50 seconds in duration, and have a frequency that ranges from 10 Hz to 100 Hz.

8. An apparatus for causing neuron depolarization for ameliorating the effects of a mental disorder, the apparatus comprising: a cap instrument configured to be placed in physical proximity to a human head, for comprising: a plurality of coils
arranged in rows on the cap configured to emit a sequence of pulses of a electromagnetic radiation when energized with electric current, wherein the pulses have a pulse frequency; and an adjustment mechanism connected to the cap for adjusting the
distance of the coils from the head for focusing the electromagnetic radiation into the head when the cap is worn by the head; three congruent thyristor connections configured to consecutively or simultaneously operate to open and close power gap
allotments; an ultrasound attachment for generating ultrasonically induced electric fields within a brain; wherein the pulses range from 50 microseconds to 400 microseconds in duration.

9. A method for treatment of depression, attention deficit disorder, anxiety, obsessive compulsive disorder, dysthymia, memory loss, learning disorder by directing a combination of electromagnetic radiation and ultrasound onto a specific area
in the brain.

10. A method for non-invasive excitation of brain neurons of a person having a mental or emotional disorder, comprising: projecting a combination of electromagnetic radiation and ultrasound pulses on to specific areas of a brain that known to
impact or result in mental or emotional disorders; wherein the ultrasound pulses are initiated from a cap configured to conform to a human head; wherein the electromagnetic radiation is initiated from a plurality of coils connected to the cap, the
electromagnetic radiation varying in time and intensity from the plurality of coils and focused on a plurality of locations in the cerebrum; wherein the combination of electromagnetic radiation and ultrasound induce neuron depolarization for the purpose
of rehabilitating the, and/or redirection of the mental or emotional disorder.

11. A method of treating a mental illness, comprising: applying an ultrasound beam to an affected area of the brain through a pathway; applying electromagnetic pulses through the pathway targeting the affected area of the brain, the
electromagnetic pulses initiated from a cap structure surrounding the brain and positioned a fixed distance from the brain; wherein the method causes neuron depolarization at the affected area. Description
